DraftSight lets you create, edit, view and markup any kind of 2D and 3D DWG file with greater ease, speed and efficiency. Only better.ĭraftSight 2023 is major software upgrade that’s proven and powerful, and includes your most asked-for capabilities and functionality. DraftSight 2023 gives you the freedom to do what you do best - no matter who you are or what you’re trying to accomplish. And the capability to seamlessly integrate with other Dassault Systèmes and SOLIDWORKS® solutions, including SOLIDWORKS PDM to easily manage your DWG designs from first inspiration to final printout.
You can now configure the task to convert DWG\DXF documents to PDF during workflow transitions or from a menu command.It’s the ability to effortlessly go from 2D drafting to 3D modeling and back again in order to optimize and maximize designs. This completes the installation of the DraftSight to PDF conversion task. Drag and drop the ‘SWPDFTaskAddin’ to the add-ins node and then drag and drop the ‘DWG\DXF Files to PDF’ task to the Tasks node of your vault.
These steps can be performed on any client install and only needs to be done once per vault. To add the DraftSight to PDF conversion task to existing vaults you will need to make sure the vault is at version 2016 SP4 or newer. You should also see the default ‘DWG\DXF Files to PDF’ task listed under the Tasks node. Once the vault creation process is complete, you will see the SWPDFTaskAddin listed in the Add-ins node. When creating a new vault, you can select to install the DraftSight to PDF conversion task on the configuration details page as shown below. The task uses DraftSight to perform the conversion process and therefore requires a DraftSight Professionalor Premiumlicense. This article will outline the steps to install the task when creating a new vault and adding the task to existing vaults. Starting with SOLIDWORKS PDM Professional 2016 SP4 you can create a task to convert DWG\DXF documents to PDF.
